Loxit 8961

Product Details

RRP: £909.00

Your Price: N/A

Mfr. Part #: 8961

Our Part #: LOX8961

Manufacturer Returns

- +

Login to buy

Description

The Electric Hi-Lo® Screen Lift 750 LED/LCD Wall Mount provides 750mm height adjustment for LCD, plasma and flat TV screens up to 95″ and 130kg in weight.

The electrically driven height adjustment operates perfectly through the size and weight ranges specified, with no adjustments required when changing screens, providing a fully future-proofed design.

The length of the floor to the centre of the screen when mounted directly on floor 515mm – 1265mm – ideal for nurseries.

To convert into floor lift, add optional 350mm Extension Legs for Screen Lift 750 Wall Mount. Extension legs are stackable to raise LED/LCD lift in increments of 350mm.

Floor to centre of the screen when using 1 set of Extension Legs mounted directly on floor 865mm – 1615mm.

Choose optional Anti-Crush Bar for additional safety.

Suits VESA patterns up to 800mm wide x 440mm high.

For VESA mount patterns to 800mm x 600mm high use optional bracket set.

A stylish TV lift with high load capacity allows large screens to be lifted effortlessly to a height convenient for the user with this wall stand.

Includes Easy Install Kit for a fast, safe and accurate install, allowing multiple fixings which are then neatly covered.

For additional safety when being used in vulnerable environments such as with young children in nurseries, those in SEN environments or wheelchair users, add optional Hi-Lo® Anti-Crush Bar for Flat Screen 1.00m. The discrete pressure sensitive bar is adhered to the underside of the screen and cuts out power to the motor at the slightest contact.

Features

750mm electric height adjustment means all users are able to access or view the screen.

Maximum weight screen 130Kg.

Universal screen mount brackets allow all makes and models of screen to be mounted on to the lift.

Electrically driven height adjustment – no heavy counterbalances.

LED/LCD lift is operated by a simple switch on coiled cable for tidiness.

12 month return to base warranty.

Wall bracket depth 40mm prevents screen wall lift conflicting with trunking and dado rails etc.

Optional 100mm wall bracket available to avoid dado rails, electrical trunking etc.

Total distance from surface of wall to rear of screen 180mm.

Hi-Lo Screen Lift Easy Install Kit speeds up installation of Screen lift 750 Wall Mount.

Ensures perfectly vertical installation of the wall mount, providing a perfect installation every time.

Simple to use and ensures the best fixing possible when used with plasterboarded walls, allowing the fixings to pick up studwork in any position up to 600mm centres.

Powder coated white colour.

Technical
Maximum screen weight 130kg.

Standard mount brackets provided for screens with VESA mounts up to 800mm w x 440mm h.

For larger VESA mount brackets, please specify optional Screen Hangers up to 800w x 600h, code 8975.

Anti Crush Bar code 8973.

750mm electric height adjustment.

Wall bracket depth 40mm

Total distance from surface of wall to rear of screen 180mm.

12 month return to base warranty.

Robust and durable steel construction.

Powder coated white colour.

Application

The wall mounted electric TV lift is used where screen height adjustability is required.

Ideal for touch screen applications, corporate presentations, digital signage and video conferencing, the Electric Hi-Lo® Screen Lift 750 LED/LCD Wall Mount allows screens up to 130kg to be effortlessly adjusted in height.

Includes Hi-Lo Screen Lift Easy Install Kit to ensure a perfect installation ensuring the columns are perfectly aligned.

Using slots in the bracket, wall fixings can pick up structural members within studwork for the best installation possible, for up to 600mm centres.

A simple, fast and perfect installation every time, enabling maximum productivity.

'Additional adapter arms may be required, PLEASE CHECK before ordering'

Don't forget...

Options

Features
Description

Features
Bracket Type	Wall
Bracket Orientation	Landscape
Bracket Function	Electric Height Adjustable
Screen Size	42 - 95 Inch
Minimum VESA Compatibility	200 x 200 mm
Maximum VESA Compatibility	800 x 600 mm
Max Weight	130 KG
Colour	Black / White
