Loxit 8420

Product Details

RRP: £839.00

Your price: N/A

Mfr. Part #: 8420

Our Part #: LOX8420

Description

Single column electric mobile screen lift.

Heavy duty electric operation with reinforced welded brackets for displays and touch screens up to 86″.

Max screen weight 130kg.

Smooth electrical operation raises and lowers the screen by 500mm, allowing all users access to the display.

Suits VESA patterns up to 800mm wide x 440mm high.

For VESA mount patterns to 800mm x 600mm high use optional bracket set 8975.

Height from floor to centre of screen:
Lowered 1035mm
Raised 1535mm

Includes integrated 4 way power strip to power the screen and peripherals with just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety.

Switched, fused power inlet also includes 3 additional IEC outlets in addition to the 4 way power strip.

Cables are tidied away within the mount head for a professional installation.

Ready assembled – simply screw the universal mount brackets onto the screen and hang on the trolley. Saves installation time and money.

Optional rubber bumper for use in nurseries and for base protection.

For additional safety when being used in vulnerable environments such as with young children in nurseries, those in SEN environments or wheelchair users, add Hi-Lo® Anti-Crush Bar for Flat Screen 1.00m code 8973. The discrete pressure sensitive bar is adhered to the underside of the screen and cuts out power to the motor at the slightest contact.

Features
Very stable and durable single column electric trolley based lift for LED/LCD screens and displays.

Max screen weight 130kg max screen size 86″ diagonal.

Smooth, quiet electrical operation raises and lowers the screen by 500mm, allowing all users access to the display.

Height from floor to centre of screen 1035 – 1535mm.

Includes integrated 4 way power strip and 2 spare IEC outlets to power the screen and peripherals.

Just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety. Country specific cables available.

Ready assembled – simply screw the universal mount brackets onto the screen and hang on the trolley – saves installation time and therefore money.

Optional rubber bumper for use in nurseries and for base protection.

Technical

500mm electric height adjustment.

Height from floor to centre of screen:
Lowered 1035mm
Raised 1535mm

Max screen size 86″

Max screen weight 130kg

Includes integrated 4 way UK power strip.

Includes 3m mains input cable.

Application

A mobile electric height adjustable display mount perfect for touch screens, digital signage and video conferencing applications where the screens are shared between user groups and between people of differing heights.

The Hi-Lo Mono 500 Electric Screen Mount is stylish and suitable for any environment. The range of screen heights makes it an excellent all round performer. Low enough for younger users and high enough for presentations. The maximum height to the centre of the screen is approximately (depending on location of screen mount holes) 1535mm from the floor, whilst in the lowered position it is 1035mm.

The smooth and effortless electric height adjustment allows users of all age groups and heights to benefit from screen technology without compromise.

The single column provides a stylish mount suitable for any environment.

Read more

Don't forget...
Options

Single column electric mobile screen lift.

Heavy duty electric operation with reinforced welded brackets for displays and touch screens up to 86″.

Max screen weight 130kg.

Smooth electrical operation raises and lowers the screen by 500mm, allowing all users access to the display.

Suits VESA patterns up to 800mm wide x 440mm high.

For VESA mount patterns to 800mm x 600mm high use optional bracket set 8975.

Height from floor to centre of screen:
Lowered 1035mm
Raised 1535mm

Includes integrated 4 way power strip to power the screen and peripherals with just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety.

Switched, fused power inlet also includes 3 additional IEC outlets in addition to the 4 way power strip.

Cables are tidied away within the mount head for a professional installation.

Ready assembled – simply screw the universal mount brackets onto the screen and hang on the trolley. Saves installation time and money.

Optional rubber bumper for use in nurseries and for base protection.

For additional safety when being used in vulnerable environments such as with young children in nurseries, those in SEN environments or wheelchair users, add Hi-Lo® Anti-Crush Bar for Flat Screen 1.00m code 8973. The discrete pressure sensitive bar is adhered to the underside of the screen and cuts out power to the motor at the slightest contact.

Features
Very stable and durable single column electric trolley based lift for LED/LCD screens and displays.

Max screen weight 130kg max screen size 86″ diagonal.

Smooth, quiet electrical operation raises and lowers the screen by 500mm, allowing all users access to the display.

Height from floor to centre of screen 1035 – 1535mm.

Includes integrated 4 way power strip and 2 spare IEC outlets to power the screen and peripherals.

Just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety. Country specific cables available.

Ready assembled – simply screw the universal mount brackets onto the screen and hang on the trolley – saves installation time and therefore money.

Optional rubber bumper for use in nurseries and for base protection.

Technical

500mm electric height adjustment.

Height from floor to centre of screen:
Lowered 1035mm
Raised 1535mm

Max screen size 86″

Max screen weight 130kg

Includes integrated 4 way UK power strip.

Includes 3m mains input cable.

Application

A mobile electric height adjustable display mount perfect for touch screens, digital signage and video conferencing applications where the screens are shared between user groups and between people of differing heights.

The Hi-Lo Mono 500 Electric Screen Mount is stylish and suitable for any environment. The range of screen heights makes it an excellent all round performer. Low enough for younger users and high enough for presentations. The maximum height to the centre of the screen is approximately (depending on location of screen mount holes) 1535mm from the floor, whilst in the lowered position it is 1035mm.

The smooth and effortless electric height adjustment allows users of all age groups and heights to benefit from screen technology without compromise.

The single column provides a stylish mount suitable for any environment.

Features
Bracket TypeScreen Lift
Bracket OrientationLandscape
Bracket FunctionElectric Height Adjustable Trolley 500mm
Minimum VESA Compatibility200 x 200 mm
Maximum VESA Compatibility800 x 600 mm
Max Weight 130 KG
ColourBlack / Silver
Screen Size42 - 86 Inch
