Loxit 8430

Product Details

RRP: £1,050.00

Your Price: N/A

Mfr. Part #: 8430

Our Part #: LOX8430

Description

Single column wall to floor mounted electric screen lift.

Heavy duty electric operation with reinforced welded brackets for displays and touch screens up to 86″.

Max screen weight 130kg.

Smooth electrical operation raises and lowers the screen by 500mm, allowing all users access to the display.

Suits VESA patterns up to 800mm wide x 440mm high.

For VESA mount patterns to 800mm x 600mm high use optional bracket set 8975.

Height from floor to centre of screen:
Lowered 882mm
Raised 1382mm

Includes levelling feet for a perfect installation.

Includes 2 sets of plasterboard installation brackets with multiple fixing points for a sturdy installation. The floor standing electric wall mount allows the weight of the large format display or touch screen to be taken directly to the floor. The wall brackets act as a restraint.

Includes integrated 4 way power strip to power the screen and peripherals with just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety.

Switched, fused power inlet also includes 3 additional IEC outlets in addition to the 4 way power strip.

Cables are tidied away within the mount head and then covered with the ventilated grille for a professional installation.

For additional safety when being used in vulnerable environments such as with young children in nurseries, those in SEN environments or wheelchair users, add Hi-Lo® Anti-Crush Bar for Flat Screen 1.00m code 8973. The discrete pressure sensitive bar is adhered to the underside of the screen and cuts out power to the motor at the slightest contact.

Features
Very stable and durable, quality electric lift for LED/LCD screens and displays.

Max screen weight 130kg.

Max screen size 86″ diagonal.

Smooth electrical operation raises and lowers the screen by 500mm, allowing all users access to the display.

Height from floor to centre of screen 882 – 1382mm.

Includes integrated 4 way power strip and 2 spare IEC outlets to power the screen and peripherals.

Just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety. Country specific cables available.

Ready assembled – simply screw the universal mount brackets onto the screen and hang on the LED/LCD wall mount, saving installation time and therefore money.

Technical
500mm electric height adjustment.

Height from floor to centre of screen:
Lowered 882mm
Raised 1382mm

Max screen size 84″

Max screen weight 130kg

Includes integrated 4 way UK power strip.

Includes 3m mains input cable.

Application
The Hi-Lo Mono Electric Wall Mount has 500mm electric travel screen wall mount and is particularly suited to younger years applications for example in nurseries and primary schools.

The maximum height to the centre of the screen is approximately (depending on location of screen mount holes) 1382mm from the floor and the minimum height is 882mm to centre of screen.

Height adjustment is perfect for touch screen and video conferencing applications where screen height is important.

The floor standing electric wall mount allows the weight of the large format display or touch screen to be taken directly to the floor. The wall brackets act as a restraint.

The smooth electric height adjustment positions the screen perfectly.

Read more

Don't forget...
Options

Single column wall to floor mounted electric screen lift.

Heavy duty electric operation with reinforced welded brackets for displays and touch screens up to 86″.

Max screen weight 130kg.

Smooth electrical operation raises and lowers the screen by 500mm, allowing all users access to the display.

Suits VESA patterns up to 800mm wide x 440mm high.

For VESA mount patterns to 800mm x 600mm high use optional bracket set 8975.

Height from floor to centre of screen:
Lowered 882mm
Raised 1382mm

Includes levelling feet for a perfect installation.

Includes 2 sets of plasterboard installation brackets with multiple fixing points for a sturdy installation. The floor standing electric wall mount allows the weight of the large format display or touch screen to be taken directly to the floor. The wall brackets act as a restraint.

Includes integrated 4 way power strip to power the screen and peripherals with just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety.

Switched, fused power inlet also includes 3 additional IEC outlets in addition to the 4 way power strip.

Cables are tidied away within the mount head and then covered with the ventilated grille for a professional installation.

For additional safety when being used in vulnerable environments such as with young children in nurseries, those in SEN environments or wheelchair users, add Hi-Lo® Anti-Crush Bar for Flat Screen 1.00m code 8973. The discrete pressure sensitive bar is adhered to the underside of the screen and cuts out power to the motor at the slightest contact.

Features
Very stable and durable, quality electric lift for LED/LCD screens and displays.

Max screen weight 130kg.

Max screen size 86″ diagonal.

Smooth electrical operation raises and lowers the screen by 500mm, allowing all users access to the display.

Height from floor to centre of screen 882 – 1382mm.

Includes integrated 4 way power strip and 2 spare IEC outlets to power the screen and peripherals.

Just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety. Country specific cables available.

Ready assembled – simply screw the universal mount brackets onto the screen and hang on the LED/LCD wall mount, saving installation time and therefore money.

Technical
500mm electric height adjustment.

Height from floor to centre of screen:
Lowered 882mm
Raised 1382mm

Max screen size 84″

Max screen weight 130kg

Includes integrated 4 way UK power strip.

Includes 3m mains input cable.

Application
The Hi-Lo Mono Electric Wall Mount has 500mm electric travel screen wall mount and is particularly suited to younger years applications for example in nurseries and primary schools.

The maximum height to the centre of the screen is approximately (depending on location of screen mount holes) 1382mm from the floor and the minimum height is 882mm to centre of screen.

Height adjustment is perfect for touch screen and video conferencing applications where screen height is important.

The floor standing electric wall mount allows the weight of the large format display or touch screen to be taken directly to the floor. The wall brackets act as a restraint.

The smooth electric height adjustment positions the screen perfectly.

Features
Bracket TypeStand
Bracket OrientationLandscape
Bracket FunctionElectric Height Adjustable
Minimum VESA Compatibility200 x 200 mm
Maximum VESA Compatibility800 x 600 mm
Max Weight 130 KG
ColourBlack / Silver
Screen Size42 - 86 Inch
