RRP: £325.00
Your Price: N/A
Mfr. Part #: B42110000
Our Part #: MAGEPCNDIAIOMOD
Description
Converts a live NDI® stream into HDMI and SDI
A hot-swappable module to be installed in Magewell Modator chassis
Decodes high-bandwidth NDI and NDI HX including earlier variants into HDMI and SDI
Centrally manageable via the Modator chassis and Magewell Control Hub
Output Features
• Support for up to 1920x1080 60fps HDMI and SDI output
• Supports 48KHz 8-channel audio output
Decoding Features
• Support for decoding up to 2Kp60 NDI streams
• Support for decoding high-bandwidth NDI and NDI HX
• Discover NDI devices across network segments
• Compatible with H.264/H.265 streams in additional protocols including RTSP, HTTP, HLS, RTMP Pull/Push, MPEG-TS over UDP/SRT/RTP and TVU
• Supports NDI 5.x
Others
• Very low latency
• Configure through the touch screen of Magewell Modator chassis, Web GUI or Control Hub
• HTTP-based APIs for custom integration
• Image flip for inverted projector installations and safe area controls
• 2-year warranty
Converts a live NDI® stream into HDMI and SDI
A hot-swappable module to be installed in Magewell Modator chassis
Decodes high-bandwidth NDI and NDI HX including earlier variants into HDMI and SDI
Centrally manageable via the Modator chassis and Magewell Control Hub
Output Features
• Support for up to 1920x1080 60fps HDMI and SDI output
• Supports 48KHz 8-channel audio output
Decoding Features
• Support for decoding up to 2Kp60 NDI streams
• Support for decoding high-bandwidth NDI and NDI HX
• Discover NDI devices across network segments
• Compatible with H.264/H.265 streams in additional protocols including RTSP, HTTP, HLS, RTMP Pull/Push, MPEG-TS over UDP/SRT/RTP and TVU
• Supports NDI 5.x
Others
• Very low latency
• Configure through the touch screen of Magewell Modator chassis, Web GUI or Control Hub
• HTTP-based APIs for custom integration
• Image flip for inverted projector installations and safe area controls
• 2-year warranty
EAN # : 6936572401553
